So no errors in bottom right for the three files I tried to open (the R14 was zero bytes so can be ignored). I have zoomed out as far as I can and tried to select items on the entire screen (using the green select all function) but nothing shows. The 2007 Binary seems to have imported properly as the errors are not showing and the layers and elements all appear to be listed BUT I cannot see anything! I just have a blank page. LibreCAD did not like the ASCII version and hung requiring a forced shutdown and restart. ODA manages the 2007 conversions but simply hangs on converting the R14 type so I have dropped trying it. OK, I have experimented using ODAFileConverter and tried to generate DXF files of type binary and ASCII 2007, and R14 (also listed in the save as dropdown). Loaded document: /Users/gjj/Desktop/FreeCAD Output/MM ALAMBIC CURRENT.dxf


I would add that it is doing something as there is a list of elements that I recognise on the RHS of the viewer together with these error messages (hence me wondering if it is a version issue). Or should it be one of the R (revision?) types R14, R13, R12, R10 or R9? Should I select an ASCII or Binary format? Can someone let me know what the most appropriate version of the DFX file is that I should use? I am using ODA File Converter.

I am trying to import a file from AutoCAD by converting it first to DXF format but there appear to be many options for the DXF type. I am a new user and am trying to see how LibreCAD works relative to my ancient copy of Autocad (2012).
